IN UK STOCK NOW
Priced as boxed matched pairs ± 0.5dB !
The OW2-92 is a top quality drop in upgrade replacement for the Linn D20-LP-2 and others.
Superb choice for active Linn Isobarik / Keltik / Kaber systems.
Also upgrades Scanspeak D2008/8511 series as found in models such as Naim IBL / SBL and many others.
If you have any questions about compatibility please contact us.
This 20mm (3/4") soft dome tweeter offers a unique analytic capability and higher sensitivity than OW1-92. A very musical and true to life tweeter! With textbook impulse response / recovery, maximum detail resolution and pair matching to within 0.5 dB, this esoteric unit projects a sublime stereo image. Excellent for use in high-end 3-way loudspeaker systems; also a great choice for 2-way systems using wide band mid-bass drivers of appropriate quality. The OW2 was designed primarily for domestic loudspeakers but is also used to high acclaim in studio monitors because of its very low distortion, analytical response and very close pair matching.
Great frequency linearity between 3 – 20 kHz, rising gently upwards - works very well in 'dead' rooms containing lots of heavy furnishings / drapes. Extremely fast transient response and excellent phase linearity.This esoteric tweeter exhibits a well controlled and damped resonance / low frequency response and gives a wide useable bandwidth of 2 kHz to 22 kHz, nominal –3 dB. Unique heavy duty 2.5mm solder bucket connectors - Hiquphon connection guide
Supplied as matched pairs to within an incredible 0.5 dB 2 kHz—20 kHz (individual graphs included), each pair is thoroughly tested before being signed off by Oskar Wrønding, the founder of Hiquphon.
Full set of datasheets can be downloaded from the bottom of this page.
Sole Authorised UK distributor.
|Resonant frequency (fs)||900 Hz||Nominal impedance (Zn)||8 Ω|
|Effective diaphragm diameter||20mm||DC resistance (Re)||5.8 Ω|
|Ferrofluid ? Y/N||No||RMS power handling||100 W|
|Recommended crossover||3kHz/12dB||Faceplate diameter||92 mm|
|Sensitivity (2.83V/1m)||90 dB||Cutout hole diameter||70 mm|
