Home / Products / Peerless D26NC-56-06 Tweeter
Peerless D26NC-56-06 Tweeter - Willys-Hifi Ltd
Peerless D26NC-56-06 Tweeter - rear view
Peerless D26NC-56-06 Tweeter - dimensions

D26NC56-06

Peerless D26NC-56-06 Tweeter

Sold Out

Notify me when this product is available:

Replaces Vifa D26NC-55-06 / D26NC-15-06

IN STOCK NOW - LAST BATCH.

ATC SCM12, SCM7a (early), SCM35, SCM25a, Hafler TRM6,Royd RR2, Royd RR3, Miller & Kreisel (various models).This is the long awaited replacement for the highly respected D26NC15-06 and D26NC55-06.

Perfect replacement, no modifications required. A downloadable datasheet is available from this page.

We recommend changing in pairs to maintain channel balance as older versions often have reduced output due to ferrofluid thickening.

Key Features:

  • Specially treated pure silk dome
  • Neodymium magnet assembly
  • Heatsink for high power handling
  • Ferrofluid cooled voice coil
  • Wide and smooth response
  • Perfect replacement for 15-06 & 55-06 variants

Basic parameters:

Resonant frequency (fs) 1625 Hz Nominal impedance (Zn) 6 Ω
Effective diaphragm diameter 26 mm DC resistance (Re) 4.68 Ω
Ferrofluid ? Y/N Yes RMS power handling 100 W
Recommended crossover 2.5 kHz 18dB Faceplate diameter (cropped profile) 70 mm
Sensitivity (2.83V/1m) 89.3 dB Cutout hole diameter 45 mm

Here's the full datasheet:

.pdf icon

Peerless by Tymphany

Customer Reviews

Based on 1 review Write a review

Categories: 0.75 - 2" (19-50mm) Dome Tweeters, Peerless (Tymphany) Drive Units - All, Peerless Tweeters
