SB Acoustics SB20PFCR30-4
SB Acoustics SB20PFCR30-4 drawing
SB Acoustics SB20PFCR30-4 graph

SB20PFCR30-4

Categories: 8-10 inch Bass Speakers SB Acoustics Midwoofers SB Acoustics Woofers

SB Acoustics SB20PFCR30-4 Paper Woofer

£33.06

SB Acoustics logo

UK STOCK ITEM

The SB Acoustics SB20PFCR30-4 is an 8 inch 4 ohm woofer bass speaker featuring a paper / pulp cone, a vented reinforced plastic chassis and an optimised motor system. A relatively low priced woofer that gives an excellent cost to performance ratio.

Also available in 8 ohms: SB20PFCR30-8.

Key Features:

  • Vented reinforced plastic chassis.
  • Proprietary cone material with natural fibers made in-house.
  • Soft low damping rubber surround for improved transient response.
  • Large spider for improved linearity.
  • Optimised motor system.
  • Vented coil former for low compression.
  • Non-resonant long life lead wires.

Basic parameters:

Resonant frequency (fs) 34 Hz Nominal impedance (Zn) 4 Ω
Mechanical  Q factor (Qms) 2.78
 DC resistance (Re) 3.4 Ω
Electrical Q factor (Qes) 0.37
 Max power handling 50 W
Total Q factor (Qts) 0.33
 Sensitivity (2.83V/1m)
 92.5dB
Equivalent volume (Vas) 66.2L Chassis diameter
 218mm

Here's the full datasheet:

.pdf link
