OC25SC65-04

Vifa Peerless OC25SC65-04 Tweeter

Vifa / Peerless OC25SC65-04 Tweeter Capsule. B&W P4, P5.

REPLACES VIFA 0C25SC05-04.


This tweeter features a 25 mm 4 ohm voice coil, a damped fabric dome giving a smooth frequency response and ferrofluid in the gap of the neodymium magnet for enhanced cooling of the voice coil. Twist-lock bayonet mounting for easy installation into custom faceplates / baffles. A full datasheet can be downloaded from the bottom of this page.

Can be supplied specially modified and prepared for easy replacement in the following B&W models: P4, P5, CDM1, CDM7SE. Not suitable for P6 or NT models. Please select which type you require from the dropdown menu.

Excellent replacement for Mission M7, M71, M72, M73, and so many others.

Key Features:

  • 25mm specially treated textile dome
  • Neodymium magnet assembly
  • Twist lock bayonet mounting
  • Wide and smooth response
  • Very compact design

Basic parameters:

Resonant frequency (fs) 1382 Hz Nominal impedance (Zn) 4 Ω
Effective diaphragm diameter 25 mm DC resistance (Re) 3.0 Ω
Ferrofluid ? Y/N Yes RMS power handling 25 W
Recommended crossover 2.5 kHz 12dB Faceplate diameter -
Sensitivity (2.83V/1m) 93.1 dB Cutout hole diameter -

Here's the full datasheet:

.pdf icon
