Name: Monacor SPH-5M Bass / Mid speaker
Brand: Monacor
SKU: SPH-5M
Price: 40.21 GBP
Availability: InStock
Rating: 5.0 (1 reviews)

High-quality long excursion 5 inch bass-midrange speaker.

Good replacement for TDL Studio 0.5.

Dampened low-resonance polypropylene cone.

Robust smooth cast alloy chassis with 6 mounting holes.

Drilled pole core and large high efficiency magnet.

For general applications in compact bass-reflex, TML and infinite baffle designs.

Can also be used as a fine midrange unit in 3-way speaker systems.

These work very well in transmission line enclosures.

We also stock an 8 inch version of this driver: Monacor SPH-8M

Key Features:

Damped Polypropylene Cone
Aluminium Voicecoil Former
Heavy Duty Die Cast Chassis
Very Smooth Response
Long Throw Design
Extension down to 34 Hz
Vented Pole Piece

Basic parameters:

Resonant frequency (fs)	45 Hz	Nominal impedance (Zn)	8 Ω
Mechanical Q factor (Qms)	2.89	DC resistance (Re)	6.3 Ω
Electrical Q factor (Qes)	0.47	Max power handling	80W
Total Q factor (Qts)	0.41	Sensitivity (2.83V/1m)	88 dB
Equivalent volume (Vas)	13.47L	Chassis diameter	150 mm

Here's the full datasheet:

SPH5M

Cracking little drive unit

This is a great driver for a transmission line or tapered pipe design. Good quality, if basic, chassis - nice and rigid with a chunky magnet. Nice smooth midrange making it easy to integrate with a range of HF units. I used the Fountek NeoX1.0 Ribbon Tweeter which is similarly an impressive unit. A good combination.

Thankyou for your review !
Will & Caroline
