Morel CAT 298 Tweeter

Morel CAT 298 Tweeter

Classic Advanced Tweeter, 8 Ohms.

Morel Logo

The Morel CAT 298 is a modern updated version of the legendary MDT-29. Featuring a field replaceable 28mm Acuflex textile dome, a large ferrofluid cooled copper voice coil, a ferrite magnet system and an aluminium faceplate, this tweeter can sound very sweet and is a excellent value. Recommended frequency use: 2000-20,000 Hz. High power rating of 80w nominal, 1000w peak.

A full datasheet can be downloaded from the bottom of this page.

Key Features:

    • 104mm Aluminium face plate
    • 28mm Acuflex™ replaceable dome / coil assembly
    • Large 2 layer copper voice coil
    • Ferrite magnet system
    • Ferro fluid cooling
    • High power handling

    Basic parameters:

    Resonant frequency (fs) 900 Hz Nominal impedance (Zn) 8 Ω
    Effective diaphragm diameter 28mm DC resistance (Re) 5.2 Ω
    Ferrofluid ? Y/N Yes RMS power handling 80W
    Recommended crossover 2khz Faceplate diameter 104mm
    Sensitivity (2.83V/1m) 89 dB Cutout hole diameter 72 mm

    Here's the full datasheet:

    .pdf icon

    CAT298
