D26NC56-06

Vifa Peerless D26NC-56-06 Tweeter

Replaces Vifa D26NC-55-06 / D26NC-15-06

UK STOCK ITEM

ATC SCM12, SCM7a (early), SCM35, SCM25a, Hafler TRM6, Royd RR2, Royd RR3, Miller & Kreisel (various models). This is the long awaited replacement for the highly respected D26NC15-06 and D26NC55-06.

Perfect replacement, no modifications required. A downloadable datasheet is available from this page.

We recommend changing in pairs to maintain channel balance as older versions often have reduced output due to ferrofluid thickening.

Key Features:

  • Specially treated pure silk dome
  • Neodymium magnet assembly
  • Heatsink for high power handling
  • Ferrofluid cooled voice coil
  • Wide and smooth response
  • Perfect replacement for 15-06 & 55-06 variants

Basic parameters:

Resonant frequency (fs) 1625 Hz Nominal impedance (Zn) 6 Ω
Effective diaphragm diameter 26 mm DC resistance (Re) 4.68 Ω
Ferrofluid ? Y/N Yes RMS power handling 100 W
Recommended crossover 2.5 kHz 18dB Faceplate diameter (cropped profile) 70 mm
Sensitivity (2.83V/1m) 89.3 dB Cutout hole diameter 45 mm

Here's the full datasheet:

.pdf icon

Peerless by Tymphany

Customer Reviews

Based on 5 reviews
100%
(5)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
R
Rowan
Replacement tweeters running with two 4-ohm 8 inch Vifa drivers wired in series

Ordered two of these tweeters on Friday afternoon NZ time, amazingly they had arrived in Auckland the following Tuesday morning, arrived in my home town of Christchurch couple of days later and were promptly installed. Seem to be doing and sound as they should, thank you for your service!

Thanks for the review Rowan, glad they arrived safely.
If that doesn't get the girls dancing nothing will !
Will & Caroline

S
Sunny Tung

Fast delivery

Thanks for the review Sunny !

Will & Caroline

D
Darren Jones
Replacement tweeters for 2003 ATC SCM 12’s

The tweeters arrived promptly and packaged really well. For size and fitting they are a perfect replacement for the 55-06 units. As regard to SQ, at the moment they sound a little bright and forward; I’m hoping this will reduce a little as they run in. Maybe my ear is just used to the old OEM tweeters that were obviously quite a few db down after 20 years. Very much looking forward to hearing how they settle over the coming weeks. Thank you.

Thanks for the review Darren !

Will & Caroline

s
sergey proshkin
speaker

Very good service. Fast and relaible.

Thanks for the review Sergey !

Will & Caroline

D
Dominic Jagger
Fantastic

Great replacement for tweeters in Royd RR2 which had very dried out Ferrofluid and were down a fair few dB. Only minor easy mods required to cutout in speaker undertaken with a file. Well worth it, speakers sounding lovely.
