SB16PFCR25-4
UK STOCK ITEM
The SB16PFCR25-4 by SB Acoustics is a 6 inch 4 ohm midwoofer speaker featuring a blended paper fibre cone, a vented reinforced plastic chassis and an optimised motor system with a high power ferrite magnet. Good efficiency, smooth extended response, excellent value.
Also available in 8 ohms: SB16PFCR25-8.
| Resonant frequency (fs) | 35 Hz | Nominal impedance (Zn) | 4 Ω |
| Mechanical Q factor (Qms) | 32.76 |
DC resistance (Re) | 3.2 Ω |
| Electrical Q factor (Qes) | 0.39 |
Max power handling | 40 W |
| Total Q factor (Qts) | 0.34 |
Sensitivity (2.83V/1m) |
89.5dB |
| Equivalent volume (Vas) | 32.7L |
Chassis diameter |
176mm |
