DRIVE UNITS BY MANUFACTURER:
30W/4558T06
Categories: 10-15 inch Bass Speakers Scanspeak Automotive
The 30W/4558T06 is the bigger brother of the 26W/4558T06 and is a dedicated automotive 12" sub bass drive unit featuring a rigid anodised Aluminium cone, double magnet with Faraday ring and a vented diecast chassis. Capable of huge output with true depth and accuracy, this is a very 'fast' sounding woofer with superb dynamics. The response is tailored specifically for the automotive environment and with a low Fs of 17Hz, huge peak excursion of 56mm + a peak power of 350 watts this woofer produces prodigious amounts of tight bass that is felt as well as heard.
Resonant frequency (fs) | 17 Hz | Nominal impedance (Zn) | 4 Ω |
Mechanical Q factor (Qms) | 5.01 | DC resistance (Re) | 2.6 Ω |
Electrical Q factor (Qes) | 0.34 | Peak long term power | 350W |
Total Q factor (Qts) | 0.32 | Sensitivity (2.83V/1m) | 89dB |
Equivalent volume (Vas) | 197L | Chassis diameter | 308mm |
