C220-6-221
Categories: 8-10 inch Bass Speakers Accuton Drive Units - All
The Accuton C220-6-221 Bass / Midrange is an esoteric 8.5 inch drive unit primarily intended for 2 and 3 way floor standing loudspeaker designs.
This high end driver features a ceramic (Sapphire) cone, soft rubber surround, large ferrite magnet and 38mm titanium former.
The spider, pole and voice coil former are fully ventilated for minimal compression. This driver has a substantial power rating of 150 watts and offers very good midrange resolution / extension for a unit of this size.
This drive unit is also available in 11 ohms impedance (for tube amps or parallel array) here : C220-11-221
Full datasheets can be downloaded from the bottom of this page.
Vented:
Vb: 51L, Port diameter: 70mm, Length: 265mm, Fres: 26.5Hz, F-3dB: 34Hz, Q: 0.58 (optimal)
Vb: 83L, Port diameter: 70mm, Length: 110mm, Fres: 29Hz, F-3dB: 28Hz, Q: 0.50 (extended bass)
Vb: 43L, Port diameter: 70mm, Length: 220mm, Fres: 31Hz, F-3dB: 35Hz, Q: 0.61 (0.7dB Ripple @ 50Hz)
Infinite baffle:
Vb: 29L, -6dB @ 40Hz, -19dB @ 20Hz, F-3dB: 50Hz, Q: 0.71 (typical)
Vb: 83L, -4.5dB @ 40Hz, -13dB @ 20Hz, F-3dB: 60Hz, Q: 0.50 (extended bass)
A matching passive radiator is available : Accuton P220
Resonant frequency (fs) | 28Hz | DC resistance (Re) | 5.8Ω |
Mechanical Q factor (Qms) | 7.4 | Power handling | 150W |
Electrical Q factor (Qes) | 0.39 | Sensitivity (2.83V/1m) | 90dB |
Total Q factor (Qts) | 0.37 | Chassis diameter | 220mm |
Equivalent volume (Vas) | 79L | Cutout diameter | 191mm |
Click icons to download :
Built to order - contact us for a lead time.
